Crawler mucking loader
STB-80S crawler belt conveyor type slag machine is a kind of high efficiency continuous production mining equipment, mainly used for narrow space mining operations, such as metal mines, non-metallic mines, water diversion tunnel, etc. Its function is collect the gravel soil of each project,transport and load. the machine is driven by the crawler. It has a large driving force and a wide range of extraction. The whole section is loaded with rock without leaving a dead corner. It does not need manual cleaning the working surface. This machine adopts hydraulic pilot operation, which is easy and convenient to operate, reliable in performance, has seats, and has a driving shed, which greatly reduces the labor intensity of workers, work easy, accurate in positioning, fast in conveying speed, has characters as safe,reliable, environmentally efficient, and manpower saving,etc. it is fully ergonomic. Its power can be divided into motor and diesel type.
| TYPE | STB-60S | STB-80S |
| WEIGHT(T) | 7.8 | 8.6 |
| DIMENSION(L*W*H) | 5000*1650*1750 | 5200*1600*1800 |
| LOADING CAPACITY(M3/H) | 60 | 80 |
| MIN.TURNING RADIUS(MM) | 5500 | 5500 |
| GRADIENT(°) | ≤20 | ≤30 |
| TRAVELING SPEED(M/MIN) | 2-4.5 | 2.1-3.8 |
| GROUND CLEARANCE(MM) | 200 | 230 |
| NOMINAL WORKING PRESSURE(MPA) | 20 | 25 |
| MOTOR POWER(KW) | 22 | 30/37 |
| MAX.MATERIALS SIZE(L*W*H) | 680*580*500 | 650*700*650 |
| APPLICABLE SECTION(W*H)M | ≥2.0*2.0 | ≥2.2*2.2/2.6*2.6 |
