SANY SYL956H 5T Mining Loader Wheel Loader China Price
Our company is committed to improving the quality of Electric Excavator, Material Loading And Discharging Machine, Crawler Mining Mucking Loader , providing satisfactory services, shaping the image of our products deeply rooted in the hearts of the people. We expect to promote the technological progress and innovation of our company and even the whole industry, and continue to grow in the direction of high integration, forming a collective brand effect. We are committed to achieving the harmonious coexistence of people, steel and the environment and improving sustainable development.
Mining Loader
Mucking loader with breaking hammer is widely used for coal driving and cutting in the narrow and restricted tunnel of coal mine,no blasting is required.
It is also used for driving and tunneling in the tunnel of metal mine,non-metal mine, hydropower project,subway and railway station project,national defence construction project etc.,no blasting is required.
Mucking loader with breaking hammer also can be used for loading bulk material in the open-air operation.
Mucking loader also can be used for danger removal with its working boom.
Mucking loader with breaking hammer can repair bottom and side of tunnel,and break bigger rock into smaller after undertaking blasting .
Use of mucking loader
.The operations of working mechanism cannot be carried out against the obstacle (such as the tunnel wall), which may cause damages to the hydraulic cylinder, hinge bolts or steel structure.
.The working mechanism cannot be used for impact operations (such as impact of embedded bed or tunnel bottom), which may cause damages to the hydraulic cylinder, hinge bolts or steel structure. The impact operations shall be avoided especially when the working mechanism is in a fully extended position and moves to the check block at the mechanical end.
.It is strictly prohibited to move the working mechanism to the extreme position of check block at the mechanical end (crank effect).
.This equipment cannot be used for lifting operations; that is, the working mechanism cannot be used to handle any materials. The working platform cannot be installed too.
.During tunneling, certain working point shall always be used as a starting point, and the tunneling shall gradually extend from that point. The continuous extension of a tunneling point can make the daily footage exceeding the continuous alternating extension of several working points.
Mucking Loader Model STB-120 Technical Data | |
Excavating Width(mm) | 5300 |
Excavating Length(mm) | 2200 |
Excavating Height(mm) | 3300 |
Excavating Depth(mm) | 700 |
Unloading Height(mm) | 1913(changeable) |
Minimum Loading Height(mm) | 1680(changeable) |
Unloading Distance(mm) | 2000(changeable) |
Maximum Rotation Angle(°) | ±50 |
Weight(T) | 12 |
Dimension | 9000x2000x2300 |
Loading Capacity(m³/hour) | 120 |
Min Turning Radius(mm) | 6000 |
Climbing Ability(°) | ≤25(hard ground) |
Travelling Speed(m/min) | 2.1-3.8 |
Electric Motor Power(kw) | 45/55 |
Maximum Material By Size(LxWxH) (mm) | 800x780x700 |
Ground Clearance(mm) | 270(changeable) |
Applied Working Section(W*H) (m) | ≥3.0x3.0 |
Nominal Working Pressure(Mpa) | 25/35 |
Applied Tunnel Gradient(°) | ≤30 |
Mining Loader
Technological innovation can effectively increase the added value of our SANY SYL956H 5T Mining Loader Wheel Loader China Price and enhance the core competitiveness of our company. Please feel free to get in touch with us if you need any further assistance. Relying on the advantages of technological innovation and honest service, we strengthen exchanges and cooperation with all walks of life, and strive to develop into one of the most professional companies in the industry.
