Professional Design Wheel Loader
Professional Design Wheel Loader
Professional design Wheel loader for underground mining,mucking machine with scraper
Mucking Loader also called hagloader or excavator loader (commonly known as: grilled slag machine), is a continuous high efficiency mining equipment.
The product is extensively used in mine slope and the vertical shaft of each kind of section of excavating roadway loading operation, and phosphate rock ore, iron ore, fierce and so on all kinds of ores mining loading operation, at the same time, the product also was widely used in building the railway tunnel, and road tunnel, diversion engineering, etc. Various kinds of tunneling engineering.
The product is a four-wheel drive, with large driving force, wide extraction range, full-section loading rock, no dead corners, no need manual auxiliary cleaning. The product is a chain conveyor material, completely replacing the belt to conveying material, and using life increased more than 30 times.
| Type | ZWY-STB-60L | ZWY-STB-100L |
| Loading capacity(m3/h) | 60 | 100 |
| Min.turning radius(mm) | 4500 | 4500 |
| Gradient(°) | <15(hard ground) | <15(hard ground) |
| Traveling speed(m/min) | 2-4.5m/min | 2-4.5m/min |
| Ground clearance(mm) | 200 | 210 |
| Nominal working pressure(Mpa) | 16/25 | 16/25 |
| Motor Power(kw) | 18.5/22 | 22/30 |
| Max.materials by size(L*W*H)MM | 810*580*500 | 810*580*500 |
| Applicable section(W*H)M | 2.0*2.0 | 2.2*2.2m |
| Weight(T) | 6.2 | 8.6 |
| Overall dimension(L*W*H) | 5800*1650*1700 | 5800*1700*1650 |
